14CH CCWDM MUX/DEMUX, Compact CWDM Modules

14CH CCWDM MUX/DEMUX, Compact CWDM Modules #CCWDM14

$228.00

HF P/N: CCWDM14

Shipping Cost: Free Shipping on orders over USD $800

Availability: in stock

*UPG Port: This is a required field.
*Monitor Port (on ABS box 100x80x10mm): This is a required field.

Qty:

Add to Wishlist

14CH CCWDM MUX/DEMUX, Compact CWDM Modules #CCWDM14

$228.00

HF P/N: CCWDM14

Shipping Cost: Free Shipping on orders overUSD $800

Availability: in stock

Description

14CH CCWDM MUX/DEMUX, Compact CWDM Modules

The 10Gtek 4CH CCWDM (Compact CWDM) MUX/DEMUX (Multiplexer/Demultiplexer) is a 4-channel CWDM device with super compact package designed for cost-effective multi-wavelength CWDM network applications. It is based on the Thin Film Filter (TFF) technology and operates at four 20nm channel spacing ITU Grid CWDM wavelengths. Gigalight provides a series of customized 4CH CCWDM MUX/DEMUX devices packaged in metal box to meet different requirements on port configuration (1310nm/upgrade ports available), fiber type, fiber length, input connector, and output connector. 10Gtek provides high quality CCWDM with flat channel bandwidth, flexible channel configuration, low insertion loss and high isolation. It is designed to upgrade capacity easily as the system grows. All 10Gtek products are epoxy-free in the optical path.

Features

● Low Insertion Loss

● Compact size

● Ultra Stable and Highly Reliable

● Extended Operating Temperature Available

Applications

● Optical Add/Drop Multiplexing

● Telecom networks

● Metro networks

● Broadband Networks

● Please note that only ABS form factor is available (Min. size: 100mm x 80mm x 10mm), when adding monitor port to this product

Performance Specifications

Parameters	4CH	4+Upgrade	8CH	8+UPG1	8+UPG2
Operating Wavelength (nm)	1260 ~ 1620	1260 ~ 1620	1260 ~ 1620	1260 ~ 1620	1260 ~ 1620
Channel Wavelength (nm)	1270, 1290, ..., 1590, 1610 or 1271, 1291, ..., 1591, 1611
Channel Spacing (nm)	20	20	20	20	20
Channel Passband (nm)	CWL+/-6.5nm	CWL+/-6.5nm	CWL+/-6.5nm	CWL+/-6.5nm	CWL+/-6.5nm
Insertion Loss (dB)	≤1.5	≤1.5	≤1.8	≤1.8	≤2.0
Channel Ripple (dB)	≤0.4	≤0.4	≤0.4	≤0.4	≤0.4
Isolation Adjacent (dB)	>30	>30	>30	>30	>30
Isolation Non-adjacent (dB)	>40	>40	>40	>40	>40
Polarization Mode Dispersion (PS)	≤0.2	≤0.2	≤0.2	≤0.2	≤0.2
Polarization Dependent Loss (dB)	≤0.2	≤0.2	≤0.2	≤0.2	≤0.2
Directivity (dB)	>45	>45	>45	>45	>45
Return Loss (dB)	>45	>45	>45	>45	>45
Maximum Power handling (mW)	500	500	500	500	500
Operating Temperature (°C)	-5 ~ +70	-5 ~ +70	-5 ~ +70	-5 ~ +70	-5 ~ +70
Storage Temperature (°C)	-40 ~ +85	-40 ~ +85	-40 ~ +85	-40 ~ +85	-40 ~ +85
Fiber Type	G657A1	G657A1	G657A1	G657A1	G657A1
Connector	TBD	TBD	TBD	TBD	TBD
Package Dimension (mm)	L55 x W45 x H6, ABS Box Min. Size: 100mm x 80mm x 10mm
*Specifications mentioned above are for device without connector.

Specifications/Parameters

Specifications/Parameters

HF P/N

CCWDM14

Manufacturer

HiFiber

Form Type

SFP+

Interface

LC Duplex

Temp. Range

0 to 70°C (32 to 158°F)

Warranty & Service

Warranty & Service

Warranty Service Pack1*: All HiFiber's products share 1-year standard warranty.
Warranty Service Pack2*: Enhanced Item (Apply to Online order at HiFiber.com)

DAC Cables (Passive)

3-Year Warranty

DAC Cables (Active)

3-Year Warranty

AOC Cable

3-Year Warranty

Fiber Optic Transceivers

3-Year Warranty

Switch, Convertors

1-Year Warranty

NIC/CNA Cards

1-Year Warranty

Optical System

1-Year Warranty

Patch Cords

3-Year Warranty

Power Adapter

0.5-Year Warranty

Consumer cable

3-Month

* Remark:

This warranty right only lies in the initial purchaser of HiFiber.com products and is not transferrable.
This warranty right do not apply to special-offer products. For special-offer products, we will remark the warranty period under the product.
The warranty clause does not include any product damage caused by improper installation, accident hazards, natural disasters, abuse, misuse, low power or over-voltage, incorrect operation, poor/ bad environmental conditions and any unauthorized disassembly, repair or modification.
The warranty clause does not apply to products with modified internal electronic information, EEPROM information, etc. Unauth
The warranty clause does not include system problems caused by third-party software, upgraded software or upgraded IOS of the connecting devices.

* Exemption Clause:

The information above is the complete warranty provisions for HiFiber.com products, which is the only effective warranty promise and will replace all written or verbal warranty commitments. Other warranties out of this clause, including decrees in other countries, provinces or locations and any indicative warranty clauses that is nonaggressive, merchantable or suited for some specific purposes, will not be recognized by HiFiber.com.
HiFiber.com has not authorized its products to be used in those critical parts that is related to device life, or other applications in which product failure or mal-function may cause injury or death. If HiFiber.com products are used in military equipments, traffic control equipments, disaster prevention systems or medical equipments, HiFiber.com will not assume any liability for any possible casualties or property loss.
HiFiber.com warranty responsibility only confines to maintenance, replacement and interest-free refund services. Any voilation of the warranty clause or law will be compensated only by maintenance, replacement or interest-free refund. To the maximum extent of law permission, HiFiber.com will not be held the responsibility to its customers or end users for any damage, expenses, loss of data, loss of income, loss of savings, loss of profits and any unavoidable or indirect damage resulted from the purchase, use or incapable function of HiFiber.com's product

15-Day money back Guarantee:

15-Day money back guarantee applies to all products sold by HiFiber.com provided that the items are new, undamaged, unmodified and in good resalable condition. If you are not satisfied with the product, you can apply return within 15 days.
All freight charges, transaction costs (bank charge or Paypal cost, etc) are the responsibility of the customer.

Returns are not acceptable if:

The products are proved to have been abused, misused, replaced, repaired, or modified.
After 15 days of delivery, returns are not acceptable. If the items are still under warranty period, customer could ask for repair or replacement.
No Return agreement was reached with a HiFiber.com sales representative before Returns.
Return process is not done based on HiFiber.com Return instructions.

more...

About Us

HiFiber.com is a leading supplier of fiber connectivity network solutions for Data Center and HPC. The main products include compatible module, direct-attach cable(DAC), active optical cable(AOC), Jump Cable, CWDM/DWDM system, network integrated card(NIC), etc. HiFiber.com is with the goal of providing quality guaranteed and cost effective products for customers all around the world.

HiFiber.com features a huge inventory of over US $1.0 million buffer stock that ready to shipped out in the same day of customers' purchase(in most cases) with no minimum orders or restocking fees.

What makes HiFiber.com completely different is the lifetime technical support. That's right, call anytime during business hours and get the help you need whether you made your purchase last week, last month, or last year! Our products are compliant with CE, RoHS, FCC, ISO9001, ISO14001 etc. and all products are environmentally friendly.
