HP ProCurve Compatible 1m(3ft) 10G SFP+ Passive DAC Twinax Cable #J9281A-B

HP ProCurve Compatible 1m(3ft) 10G SFP+ Passive DAC Twinax Cable

HP ProCurve Compatible 1m(3ft) 10G SFP+ Passive DAC Twinax Cable #J9281A-B

$14.00

HF P/N: CAB-10GSFP-P1M-30

Shipping Cost: Free Shipping on orders over USD $300

Availability: in stock

loading...

HP ProCurve Compatible 1m(3ft) 10G SFP+ Passive DAC Twinax Cable #J9281A-B

$14.00

HF P/N: CAB-10GSFP-P1M-30

Shipping Cost: Free Shipping on orders overUSD $300

Availability: in stock

Description

HP ProCurve Compatible 1m(3ft) 10G SFP+ Passive DAC Twinax Cable

QSFP+ Extender Solutions
Used for long-distance transmission under 40G QSFP+. The QSFP+ Port could be transferred/converted into 4x SFP+ port by Direct Attach Copper (DAC) technology under very low insert lose.
Learn More
Learn More
Cisco 10GBASE-LR SFP+ Optical Transceiver Connectivity Solutions
What is the simplest cabling solution for connecting two Cisco switches with two 10GBASE-LR SFP+ optical transceivers?
Learn More
Learn More
Quick Overview: SFP+Twinax Cable Assembly is a 10GbE solution which connects 10Gb/s host systems at a much lower cost than optical transceivers. Description: Hifiber's SFP+Copper Twinax cables are suitable for very short distances and offer a highly cost-effective way to connect within racks and across adjacent racks. SFP+ cables offers a low cost SFP+ solution. SFP+ directly attached twinax cable assemblies supports 10 Gigabit Ethernet, 10 Fibre Channel, and other industry standards.This cable is available at lengths from 0.5m to 12m. Specifications: ● HP J9281A/B (1meter), ProCurve 10-GbE SFP+ 1m Direct Attach Cable ● SFP+ to SFP+ ● 10Gb/s ● 1 Meter Applications: ● 1-8G Fiber Channel and 1-10G Gigabit Ethernet ● Networking, Storage, Telecommunications ● Hub, Switches, Routers, Servers, Network Interface Card(NICs) For HP ProCurve: J9281A HP ProCurve 10-GbE SFP+ 1m Direct Attach Cable J9281B HP ProCurve 10-GbE SFP+ 1m Direct Attach Cable J9283A HP ProCurve 10-GbE SFP+ 3m Direct Attach Cable J9283B HP ProCurve 10-GbE SFP+ 3m Direct Attach Cable J9285A HP ProCurve 10-GbE SFP+ 7m Direct Attach Cable J9285B HP ProCurve 10-GbE SFP+ 7m Direct Attach Cable J9286B HP ProCurve 10-GbE SFP+ 10m Direct Attach Cable J9287B HP ProCurve 10-GbE SFP+ 15m Direct Attach Cable For Cisco: SFP-H10GB-CU1M Cisco 10GBASE-CU passive Twinax SFP+ cable assembly, 1 meter SFP-H10GB-CU1-5M Cisco 10GBASE-CU passive Twinax SFP+ cable assembly, 1.5 meters SFP-H10GB-CU2M Cisco 10GBASE-CU passive Twinax SFP+ cable assembly, 2 meters SFP-H10GB-CU2-5M Cisco 10GBASE-CU passive Twinax SFP+ cable assembly, 2.5 meters SFP-H10GB-CU3M Cisco 10GBASE-CU passive Twinax SFP+ cable assembly, 3 meters SFP-H10GB-CU5M Cisco 10GBASE-CU passive Twinax SFP+ cable assembly, 5 meters SFP-H10GB-ACU7M Cisco 10GBASE-CU active Twinax SFP+ cable assembly, 7 meters SFP-H10GB-ACU10M Cisco 10GBASE-CU active Twinax SFP+ cable assembly, 10 meters For Arista: CAB-SFP-SFP-0.5M 10GBASE-CR SFP+ Cable 0.5 Meter CAB-SFP-SFP-1M 10GBASE-CR SFP+ Cable 1 Meter CAB-SFP-SFP-2M 10GBASE-CR SFP+ Cable 2 Meter CAB-SFP-SFP-3M 10GBASE-CR SFP+ Cable 3 Meter CAB-SFP-SFP-5M 10GBASE-CR SFP+ Cable 5 Meter CAB-SFP-SFP-7M 10GBASE-CR SFP+ Cable 7 Meter For H3C: LSWM1STK H3C 10G SFP+ cables to connect the SFP+,0.65 Merter LSWM2STK H3C 10G SFP+ cables to connect the SFP+,1.2 Meters LSWM3STK H3C 10G SFP+ cables to connect the SFP+,3 Meters LSTM1STK H3C 10G SFP+ cables to connect the SFP+,5 Meters LSWM4STK H3C 10G SFP+ cables to connect the SFP+,10 Meters For Brocade: 10G-SFPP-TWX-0101 (1-pack) 10 Gbps SFP+ direct-attached cables, 1 m Twinax copper cable 10G-SFPP-TWX-0301 (1-pack) 10 Gbps SFP+ direct-attached cables, 3 m Twinax copper cable 10G-SFPP-TWX-0501 (1-pack) 10 Gbps SFP+ direct-attached cables, 5 m Twinax copper cable For Blade: BN-SP-CBL-1M SFP+ Copper Direct Attach Cable，1M BN-SP-CBL-3M SFP+ Copper Direct Attach Cable，3M BN-SP-CBL-5M SFP+ Copper Direct Attach Cable，5M BN-SP-CBL-8M5 SFP+ Copper Direct Attach Cable，8.5M For Extreme: 10304 10 Gigabit Ethernet SFP+ passive cable assembly, 1m length 10305 10 Gigabit Ethernet SFP+ passive cable assembly, 3m length 10306 10 Gigabit Ethernet SFP+ passive cable assembly, 5m length 10307 10 Gigabit Ethernet SFP+ passive cable assembly, 10m length For Force10: CBL-10GSFP-DAC-0.5M SFP+ Direct attach cable 0.5 M CBL-10GSFP-DAC-1M SFP+ Direct attach cable 1 M CBL-10GSFP-DAC-5M SFP+ Direct attach cable 5 M CBL-10GSFP-DAC-7M SFP+ Direct attach cable 7 M CBL-10GSFP-DAC-10M SFP+ Direct attach cable 10 M For Intel: XDACBL1M (1 meter) Intel? Ethernet SFP+ Twinaxial Cable, 1 meter XDACBL3M (3 meter) Intel? Ethernet SFP+ Twinaxial Cable, 3 meters XDACBL5M (5 meter) Intel? Ethernet SFP+ Twinaxial Cable, 5 meters For Juniper: SFP+ twinax copper cable(Passive) QFX-SFP-DAC-1M SFP+ 10 Gigabit Ethernet Direct Attach Copper (twinax copper cable) 1 m QFX-SFP-DAC-3M SFP+ 10 Gigabit Ethernet Direct Attach Copper (twinax copper cable) 3 m QFX-SFP-DAC-5M SFP+ 10 Gigabit Ethernet Direct Attach Copper (twinax copper cable) 5 m SFP+ twinax copper cable(Active) QFX-SFP-DAC-1MA SFP+ 10 Gigabit Ethernet Direct Attach Copper (active twinax copper cable) 1 m QFX-SFP-DAC-3MA SFP+ 10 Gigabit Ethernet Direct Attach Copper (active twinax copper cable) 3 m QFX-SFP-DAC-5MA SFP+ 10 Gigabit Ethernet Direct Attach Copper (active twinax copper cable) 5 m QFX-SFP-DAC-7MA SFP+ 10 Gigabit Ethernet Direct Attach Copper (active twinax copper cable) 7 m QFX-SFP-DAC-10MA SFP+ 10 Gigabit Ethernet Direct Attach Copper (active twinax copper cable) 10 m

Specifications

  • SFP+ to SFP+ Connetor
  • Copper Passive
  • 1 Meter
  • AWG24/AWG30
  • Compliant to SFP MSA
  • Low power consumption
  • Excellent EMI performance
  • High reliability
  • RoHS Compliant
  • Wide operating temperature range:
  • Standard: 0oC to +70oC
  • Industrial: -40oC to +85oC

Applications

Specifications/Parameters

Specifications/Parameters

HF P/N
CAB-10GSFP-P1M-30
Manufacturer
HiFiber
AWG
30AWG
Length
1m
Max Data Rate
10Gbps
Temp. Range
0 to 70°C (32 to 158°F)
