Cisco QSFP-100G-CU3M Compatible 3m(10ft) 100G QSFP28 Passive DAC Twinax Cable,26AWG #QSFP-100G-CU3M

Cisco QSFP-100G-CU3M Compatible 3m(10ft) 100G QSFP28 Passive DAC Twinax Cable,26AWG #QSFP-100G-CU3M

$89.00

HF P/N: CAB-ZQP/ZQP-P3M

Shipping Cost: Free Shipping on orders over USD $800

Availability: in stock

loading...

Cisco QSFP-100G-CU3M Compatible 3m(10ft) 100G QSFP28 Passive DAC Twinax Cable,26AWG #QSFP-100G-CU3M

$89.00

HF P/N: CAB-ZQP/ZQP-P3M

Shipping Cost: Free Shipping on orders overUSD $800

Availability: in stock

Description

Cisco QSFP-100G-CU3M Compatible 3m(10ft) 100G QSFP28 Passive DAC Twinax Cable,26AWG

QSFP+ Extender Solutions
Used for long-distance transmission under 40G QSFP+. The QSFP+ Port could be transferred/converted into 4x SFP+ port by Direct Attach Copper (DAC) technology under very low insert lose.
Learn More
Learn More
Cisco 10GBASE-LR SFP+ Optical Transceiver Connectivity Solutions
What is the simplest cabling solution for connecting two Cisco switches with two 10GBASE-LR SFP+ optical transceivers?
Learn More
Learn More
Hifiber'sQSFP28 passive copper cable assembly features eight differential copper pairs, providing four data transmission channels at speeds up to 28Gbps per channel, and meets 100G Ethernet (4x 25Gbps) and InfiniBand EDR (Enhanced Data Rate) requirements. These 100G copper cable assembly features a unique construction with individually wrapped Twinax pairs, resulting in low insertion loss and low crosstalk.

Features

  • Supports aggregate data rates of 100Gbps
  • 3 Meters
  • AWG26
  • Low insertion loss and low cross talk
  • Wide operating temperature range:
  • Standard: 0ºC to +70ºC

    Industrial: -20ºC to +80ºC

Applications

  • Low EMI radiation Switches, servers and routers
  • Data Center networks
  • Storage area networks
  • High performance computing
  • Telecommunication and wireless infrastructure
  • Medical diagnostics and networking Test and measurement equipment

Compliant

  • 100G Ethernet (IEEE 802.3bj)
  • InfiniBand EDR
  • SFF-8665
  • RoHS compliant
Specifications/Parameters

Specifications/Parameters

HF P/N
CAB-ZQP/ZQP-P3M
Brands
Cisco
Manufacturer
HiFiber
AWG
26AWG
Length
3m
Max Data Rate
100Gbps
Temp. Range
0 to 70°C (32 to 158°F)
